Palomar Knot vs. Uni Knot With Braided Line [Strength Test]
- By: Luke Simonds
- on
- Found In: Fishing Knots, Fishing Tips, Knot Contest, WEEKLY NEWSLETTER: 8-30-20
It’s knot test time!
In this video, we’re going to be testing the palomar knot vs. the uni knot when tied with braid line.
These are both extremely popular knots since they are great knots have been around for a very long time.
Since these knots came into popularity when monofilament line was pretty much the only option, we decided to run a test on them for how they hold up when tied with braid fishing line.
Is one better than the other for braid?
As it turns out, yes, one is!
Although both knots are very secure (neither of the knots pulled out during the test), they do have different breaking strengths, which essentially means that one is stronger (and can handle a bigger fish) than the other.
We’re finally able to quantify exactly how much the difference in breaking strength is between these two knots and it’s pretty significant.
Check out the video below to see the experiment and learn which knot is stronger.
Palomar Knot vs. Uni Knot [VIDEO]
Click here to join the Insider Club
Mentioned articles:
To test these knots, I first tied each end of a piece of line with the two different knots to two swivels.
Then, I used my knot strength testing machine to put tension on the knots and see which one broke first.
Just like in my previous tests, the palomar knot broke first, but with this new machine I was finally able to quantify how strong it is.
It broke at 18.36 lbs. of force, which, for using 10 lb. line, is pretty strong!
However, since it broke first, that means that the uni knot is stronger.
After a few tests where each knot to the swivel was a uni knot, I found that the average breaking strength was 20.21 lbs.
This is a little over 1.5 pounds, or 8% stronger than the palomar knot.
Conclusion
Since which knots you choose to tie is one of the few things under your control when fighting a fish, I’d definitely recommend going with the uni knot over the palomar knot.
It’s 8% stronger, so just by choosing the uni knot you can increase the pulling strength of your setup by 8%.
Nobody wants to lose a big fish because they tied a weak knot, so remember this test next time to you go tie a snug knot with braided line.
What’s your favorite snug knot with braided line?
Are there any other knots you’d like to see tested against each other?
Let me know down in the comments!
And if you know someone who loves the palomar knot, please TAG or SHARE this with them!
P.S. Want access to our best fishing spots and tips, plus discounts to our online tackle store? Click here to join us in the Insider Club!
Related articles:
Related categories:
STOP WASTING TIME ON THE WATER!
Do what the “SMART ANGLERS” are doing and join the Insider Club.
Here’s what you’ll receive today when you join:
- Weekly fishing reports and TRENDS revealing exactly where you should fish every trip
- Weekly “spot dissection” videos that walk you through all the best spots in your area
- Exclusive fishing tips from the PROS you can’t find anywhere else
- Everything you need to start catching fish more consistently (regardless if you fish out of a boat, kayak, or land).
I would go with the uni knot too I have heard the same thing every person i have experienced fishing with same thing and also this might sound crazy but I am 9 years old free time at school and know how to use bait caster spinning reels and spin cast of course.
Were you under the influence of alcohol or drugs before you done this test , have you done bumped your head? you may need to go see your doctor and get your medication changed and get your head examined. Lol Since you like the uni not so much I’ll give you a little tidbit . When you tie braid to fluoro, tie the red Phillips knot,its faster to tie and smaller than the uni to uni, it will go through your guides much better. It’s even small enough to go through micro guides ,, where uni to uni will not. But the main reason I was bringing it up is I would like to know the strength of it , I don’t think anyone has ever tested it. Thank you . Uni stronger than a palomar lololol I appreciate it I needed a good laugh today.
I have tested the Red Phillips knot, and it is slightly weaker than the double uni knot since the one side involves the simple overhand knot vs. the coils of the uni which allows for more surface area friction to get it more strength.
For the record, I only think that the Uni knot is great for beginners since it works well for so many different line types/sizes. But for more advanced fishermen who are looking for max strength while minimizing line diameter, the FG knot is MUCH better since it is proven to be 20%+ stronger while being 40% thinner.
As for the Palomar, it’s a great knot for connecting to hooks with mono/fluoro line. But it’s not nearly as good for braid line which requires more surface area friction to stay intact when under pressure which is why the improved Uni (twice through hook eye and then 7 uni twists) beat the Palomar in the test above.
You are of course welcome to test these knots out yourself because it’s super easy to do head-to-head challenges by simply tying them both to a single strand of line, and then pulling on it until the weaker one breaks.
This knot needs to be used more when you talk about the uni knot
The name isn’t right in the video however it’s way better than the regular uni by far
https://youtu.be/eTUQjMvcnfI?si=kNjWfs9Ep3DY0alu
Hi Luke,
I’m not convinced you have statistical significance on this test. To get to statistical significance, you need to calculate the accuracy and precision. Try 10 uni to uni and 10 palomar to palomar, then run a students t-test. Interesting fact, students t-test was invented to test one batch of Guinness stout vs another.
Thanks for this fantastic collection of information,
The Count
Thanks for sharing the helpful feedback. I understand that running larger sample sizes will help increase the accuracy of the results. The core goal of these tests are simply to get a basic understanding of which knots are noticeably better than others… if it’s close, we can simply assume that both knots are close enough to not require someone to switch from one to the other.
Have you tested or reviewed the World’s Fair knot? Vic Dunaway said in his book it has tested at 100% strength and is easy to tie. Curious how its stats would look on your tests.
I did try this knot and found it to be tougher to tie than the Palomar. Based on their designs, the hold strength would be very similar between the two.
why did all break at the top and not the bottom? i use the uni at times braid to cork but use loop to everything else.palomar is ruff on cork and if not tied right on hook it will fail. bad eyes can’t see it on itself and not half on leader.
Most knots seem to break at the first hard turn in the line… in most cases, the line from a uni knot pulls through cleanly since it is surrounded by coils.
What about a double palomar knot? Probably still not as good but if it narrows the gap, would be interesting to know.
You tube “How to tie GT knot, single leader braid to mono.
I finally had some time to do some research and testing on the GT knot… here’s what I found: https://saltstrongdev.wpengine.com/articles/gt-knot/
I tie the GT single line knot with the leader in a figure 8 then run the braid through both leader loops. Tighten the figure 8. Then tie the braid in a uni knot. Tighten it up and pull together. Seems very strong. Could you maybe test it. ?
Couple vids on you tube show it this way instead of the doubles line.
That knot will be pretty good, but its breaking strength will most likely be weaker than the normal double uni and it will definitely be much weaker than the FG knot.
I finally had some time to do some research and testing on the GT knot… here’s what I found: https://saltstrongdev.wpengine.com/articles/gt-knot/
Good article, but as strong as the uni knot is, the “double uni” is even better, especially with braid-to-mono /floro leader splices!!
Thanks Park! Yes, the double uni is a very good knot for braid to mono/fluoro. Have you tried the FG knot yet? I tested the FG vs. the Double Uni and I was blown away by how much stronger the FG knot was… over 30% stronger in the tests. Here’s a link on how to tie it in case you haven’t seen it yet: https://saltstrongdev.wpengine.com/articles/fg-knot/
